Jenis - jenis Sambungan Las - Types of Joints of Welding

 Types of Joints

•Two pieces aligned on the same plane



•Uses a groove weld





Lap joint

•Two pieces joined together, aligned on the same plane and that overlap

•Uses a fillet weld





Corner joint

•Two pieces are joined to form a right angle.

•Can be an open joint, partially open joint, or a closed joint.

•An open corner uses a fillet weld.

•A partially open or closed joint uses a groove weld.











T- joint

•Two pieces are joined together to form a T- shape.

•Uses a fillet weld.

Edge joint

•Two pieces are joined at the edges.
